Prerequisites

SSO Prerequisites

• Have sufficient privileges to create & configure an OIDC application.

Moveworks SSO Prerequisites

• Your Moveworks Environment should be initialized in order to continue. (Verify with your Account Team if this has been completed)
• Note the following values.
  • data_center_domain - the data center where your organization is hosted (see table below).

    Data Center	data_center_domain
    United States (default)	moveworks.com
    Canada	am-ca-central.moveworks.com
    EU	am-eu-central.moveworks.com
    Australia / Asia Pacific	am-ap-southeast.moveworks.com
    Government Secure Cloud	moveworksgov.com

  • subdomain - your organization’s login subdomain. This should match your customer_id, which can beverified from the General Information Page.

    🚧 Warning

    Make sure to use the unique subdomain. For example, if you’re organization’s login subdomain is acme.moveworks.com, then your subdomain is acme and your data_center_domain is moveworks.com which is part of the US Data center.

  • customer_id - The unique identifier for your organization . This is stored as Org Name under Organization Details > General Information

    ❗️ The Org name cannot be changed. Once set, the same value should be used in all cases.

    In exceptional cases where you would like Moveworks to support your organisation with a different subdomain value. Please reach out to Moveworks Support.

Configuration Steps

Create OIDC Application

Go to your SSO Admin Portal & create a new OpenID Connect (OIDC) application. Please configure your redirect and login urls based on your Moveworks SSO properties.

1. App Name: Moveworks.

2. Sign-in Method: OpenID Connect as the sign in method.

3. Login URL (aka Home Page URL): https://{{subdomain}}.{{data_center_domain}}

4. Redirect URL: https://{{subdomain}}.{{data_center_domain}}/login/sso/oidc

5. Application Icon:




Add OIDC Configuration in MyMoveworks

1. Note your OIDC Configuration variables from your SSO platform
   • Issuer URL: (called idp_issuer)
   • Client ID: (called idp_client_id)
   • Client Secret (called idp_client_secret)
2. Navigate to SSO Settings in MyMoveworks
3. If you already see a studio config, edit it. Otherwise, choose Create.
4. Add your configuration using the values you’ve noted above
   • Moveworks Product: studio
   • Select Connector: moveworks or {{your_idp}}
   • Authentication Protocol: OIDC
   • IDP Redirect URL: https://{{subdomain}}.{{data_center_domain}}/login/sso/oidc
     • e.g. https://acme.am-eu-central.moveworks.com/login/sso/oidc
   • IDP Issuer: idp_issuer(from Step 1)
     • e.g. https://login.microsoftonline.com/9ed5798c-9bbe-471c-8005-7658c9846400/v2.0
   • IDP Client Id: idp_client_id (from Step 1)
   • IDP Client Secret: idp_client_secret (from Step 1)
5. Click Submit.
6. Wait a few minutes, then attempt to log into your instance at https://{{subdomain}}.{{data_center_domain}}
